Specifications:
-
Intel Form Factor: ATX12V
-
PFC Type: Active PFC
-
ATX Standard: ATX 3.0
-
Dimensions: 180 x 150 x 86 mm
-
Efficiency: 80 PLUS Gold
-
MTBF: >120,000 hrs @ 25°C
-
Protection Features: OPP, OVP, UVP, SCP, OCP, OTP
-
Hazardous Materials: ROHS
-
AC Input Range: 100-240 Vac
-
DC Output Voltage:
-
+3.3V: 22A
-
+5V: 22A
-
+12V: 62.5A
-
-12V: 0.3A
-
+5Vsb: 3A
-
-
Combined Load:
-
+3.3V: 120W
-
+5V: 120W
-
+12V: 750W
-
-12V: 3.6W
-
+5Vsb: 15W
-
-
Total Output: 750W
-
Cable Connectors:
-
MB 24/20-pin x 1
-
CPU 4+4-pin x 2
-
PCI-E 16-pin x 1 (both PSU & component side)
-
PCI-E 8-pin x 3
-
SATA x 5
-
Peripheral x 4
-
-
Package Contents:
-
Power Cord x 1
-
Motherboard Power Cable x 1 (600mm)
-
CPU Cable x 2 (650mm)
-
PCI-E Gen 5 16-pin Cable x 1 (675mm)
-
PCI-E 1-to-1 Cable x 1 (675mm)
-
PCI-E (16-pin to 8-pin-8-pin) Cable x 1 (675mm)
-
SATA 1-to-2 Cable x 1 (400+120mm)
-
SATA 1-to-3 Cable x 1 (400+120+120mm)
-
Peripheral 1-to-4 Cable x 1 (400+150+150+150mm)
-
Addressable RGB Cable x 1 (800mm)
-
User Manual x 1
-
-
Weight: 2.689 kg (single PSU)
-
AURA SYNC: ARGB
-
Cybenetics Noise Level Certification: A++
-
0dB Technology: Supported (fan shuts off at low load)
-
0dB Fan Button: Yes (controls fan operation based on load)
