SPECIFICATIONS
General Specifications |
|
| Platform | Desktop |
| Market Segment | Mainstream Desktop |
| Product Family | Product Family |
| Product Line | AMD Ryzen™ 3 Desktop Processors |
| Consumer Use | Yes |
| Regional Availability | Global, China, NA, EMEA, APJ, LATAM |
| Former Codename | "Renoir" |
| Architecture | "Zen 2" |
| # of CPU Cores | 4 |
| Multithreading (SMT) | Yes |
| # of Threads | 8 |
| Max. Boost Clock | Up to 4.0GHz |
| Base Clock | 3.8GHz |
| L1 Cache | 256KB |
| L2 Cache | 2MB |
| L3 Cache | 4MB |
| Default TDP | 65W |
| CPU-AMD-AM4-RY34100 | TSMC 7nm FinFET |
| CPU Compute Die (CCD) Size | 180mm² |
| Package Die Count | 1 |
| Unlocked for Overclocking | Yes |
| CPU Socket | AM4 |
| Socket Count |
1P
|
| Supporting Chipsets |
X570
X470
B550
B450
B350
A520
A320
|
| CPU Boost Technology | Precision Boost 2 |
| Instruction Set | x86-64 |
| Supported Extensions | AES, AMD-V, AVX, AVX2, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 |
| Thermal Solution (PIB) | AMD Wraith Stealth |
| Max. Operating Temperature (Tjmax) | 95°C |
| Launch Date | 4/4/2022 |
| *OS Support |
Windows 11 - 64-Bit Edition
Windows 10 - 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit
*Operating System (OS) support will vary by manufacturer.
|
Connectivity |
|
| USB Type-C® Support | Yes |
| Native USB 3.2 Gen 2 (10Gbps) Ports | 4 |
| Native USB 3.2 Gen 1 (5Gbps) Ports | 0 |
| Native USB 2.0 (480Mbps) Ports | 0 |
| Native SATA Ports | 2 |
| PCI Express® Version | PCIe 3.0 |
| Native PCIe® Lanes (Total/Usable) | 24/20 |
| Additional Usable PCIe Lanes from Motherboard |
AMD X570 16x Gen 3
AMD X470 2x Gen 3
AMD X470 8x Gen 2
|
| NVMe Support | Boot, RAID0, RAID1, RAID10 |
| System Memory Type | DDR4 |
| Memory Channels | 2 |
| Max. Memory | 128GB |
| System Memory Subtype | UDIMM |
| System Memory Specification | Up to 3200MHz |
| Max Memory Speed |
2x1R DDR4-3200
2x2R DDR4-3200
4x1R DDR4-2933
4x2R DDR4-2667
|
| ECC Support | No |
Graphics Capabilities |
|
| Integrated Graphics | No |
| Graphics Model | Discrete Graphics Card Required |
Product IDs |
|
| Product ID Boxed |
100-100000510BOX
|
|
Product ID Tray
|
100-000000510 |
Key Features |
|
| Supported Technologies |
AMD StoreMI Technology
AMD "Zen 2" Core Architecture
AMD Ryzen™ VR-Ready Premium
|
