HIKVISION DS-2CE76D0T-ITPFS(3.6) 2MP EXIR20M 4IN1 INDOOR TURRET CAMERA

0 Review
₱900.00
Availability: In stock
SKU:
SUR-HIK-CAM-DS2CE76D0TITPFS-3.6

The HIKVISION DS-2CE76D0T-ITPFS(3.6) is a 2 MP coaxial audio camera designed to enhance safety with its discreet built-in microphone, which transmits high-quality audio over the coaxial cable. Featuring EXIR 2.0 technology, it provides advanced infrared illumination with a 20-meter range for clear night-time imaging. This versatile turret camera supports four switchable signals (TVI/AHD/CVI/CVBS), offering flexible installation options and reliable performance.

Brands:

Specification:

  • Image Sensor:

    • Type: 2 MP CMOS

  • Max. Resolution:

    • 1920 (H) × 1080 (V)

  • Min. Illumination:

    • 0.01 Lux @ (F2.0, AGC ON)
    • 0 Lux with IR

  • Shutter Time:

    • PAL: 1/25 s to 1/50,000 s
    • NTSC: 1/30 s to 1/50,000 s

  • Day & Night:

    • ICR (Infrared Cut Filter Removal)

  • Angle Adjustment:

    • Pan: 0° to 360°
    • Tilt: 0° to 75°
    • Rotation: 0° to 360°

  • Signal System:

    • PAL/NTSC

Lens

  • Lens Type:

    • 2.8 mm, 3.6 mm, 6 mm fixed lens

  • Focal Length & FOV:

    • 2.8 mm:
      • Horizontal FOV: 106.4°
      • Vertical FOV: 57.9°
      • Diagonal FOV: 124.6°
    • 3.6 mm:
      • Horizontal FOV: 79.6°
      • Vertical FOV: 43.5°
      • Diagonal FOV: 93.7°
    • 6 mm:
      • Horizontal FOV: 51.9°
      • Vertical FOV: 30°
      • Diagonal FOV: 58.8°

  • Lens Mount:

    • M12


  • Image Parameters Switch:

    • STD/HIGH-SAT

  • Image Settings:

    • Brightness
    • Sharpness
    • Mirror
    • Smart IR

  • Frame Rate:

    • TVI: 1080P@30fps, 1080P@25fps
    • AHD: 1080P@30fps, 1080P@25fps
    • CVI: 1080P@30fps, 1080P@25fps
    • CVBS: PAL/NTSC

  • Day/Night Mode:

    • Auto/Color/BW (Black and White)

  • Wide Dynamic Range (WDR):

    • Digital WDR

  • Image Enhancement:

    • Yes

  • White Balance:

    • Auto/Manual

  • AGC (Automatic Gain Control):

    • Support

Interface

  • Video Output:
    • Switchable TVI/AHD/CVI/CVBS

General

  • Material:

    • Plastic

  • Dimension:

    • Φ 84.6 mm × 78.9 mm (Φ 3.33" × 3.11")

  • Weight:

    • Approx. 140.5 g (0.31 lb.)

  • Operating Condition:

    • Temperature: -40°C to 60°C (-40°F to 140°F)
    • Humidity: 90% or less (non-condensing)

  • Communication:

    • HIKVISION-C

  • Language:

    • English

  • Power Supply:

    • 12 VDC ± 25%

  • Power Consumption:

    • Max. 2.7 W

  • IR Range:

    • Up to 20 m

Additional Features

  • Built-in Microphone:

    • Yes

  • Model:

    • HIKVISION DS-2CE76D0T-ITPFS(3.6) 2MP EXIR20M 4IN1 Indoor Turret Camera
More Information
Color White
