Specifications:
-
Essentials
-
Product Collection: 12th Generation Intel® Core™ i5 Processors
-
Code Name: Products formerly Alder Lake
-
Vertical Segment: Desktop
-
Processor Number: i5-12400
-
Lithography: Intel 7
-
Recommended Customer Price: $211.00-$221.00
-
Marketing Status: Launched
-
Launch Date: Q1'22
-
Embedded Options Available: Yes
-
Use Conditions: PC/Client/Tablet
-
-
CPU Specifications
-
Total Cores: 6
-
# of Performance-cores: 6
-
# of Efficient-cores: 0
-
Total Threads: 12
-
Max Turbo Frequency: 4.40 GHz
-
Performance-core Max Turbo Frequency: 4.40 GHz
-
Performance-core Base Frequency: 2.50 GHz
-
Cache: 18 MB Intel® Smart Cache
-
Total L2 Cache: 7.5 MB
-
Processor Base Power: 65 W
-
Maximum Turbo Power: 117W
-
-
Memory Specifications
-
Max Memory Size (dependent on memory type): 128 GB
-
Memory Types: Up to DDR5 4800 MT/s, Up to DDR4 3200 MT/s
-
Max # of Memory Channels: 2
-
Max Memory Bandwidth: 76.8 GB/s
-
-
GPU Specifications
-
GPU Name: Intel® UHD Graphics 730
-
Graphics Base Frequency: 300 MHz
-
Graphics Max Dynamic Frequency: 1.45 GHz
-
Graphics Output: eDP 1.4b, DP 1.4a, HDMI 2.1
-
Execution Units: 24
-
Max Resolution (HDMI): 4096 x 2160 @ 60Hz
-
Max Resolution (DP): 7680 x 4320 @ 60Hz
-
Max Resolution (eDP - Integrated Flat Panel): 5120 x 3200 @ 120Hz
-
DirectX Support: 12
-
OpenGL Support: 4.5
-
OpenCL Support: 3.0
-
Multi-Format Codec Engines: 1
-
Intel® Quick Sync Video: Yes
-
Intel® Clear Video HD Technology: Yes
-
# of Displays Supported: 4
-
Device ID: 0x4692 / 0x4682
-
-
Expansion Options
-
Direct Media Interface (DMI) Revision: 4.0
-
Max # of DMI Lanes: 8
-
Scalability: 1S Only
-
PCI Express Revision: 5.0 and 4.0
-
PCI Express Configurations: Up to 1x16+4, 2x8+4
-
Max # of PCI Express Lanes: 20
-
-
Package Specifications
-
Sockets Supported: FCLGA1700
-
Max CPU Configuration: 1
-
Thermal Solution Specification: PCG 2020C
-
TJUNCTION: 100°C
-
Package Size: 45.0 mm x 37.5 mm
-
Max Operating Temperature: 100 °C
-
-
Advanced Technologies
-
Intel® Gaussian & Neural Accelerator: 3.0
-
Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
-
Intel® Optane™ Memory Supported: Yes
-
Intel® Speed Shift Technology: Yes
-
Intel® Turbo Boost Technology: 2.0
-
Intel® Hyper-Threading Technology: Yes
-
Intel® 64: Yes
-
Instruction Set: 64-bit
-
Instruction Set Extensions: Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
-
-
Security & Reliability
-
Intel® Threat Detection Technology (TDT): Yes
-
Intel® Standard Manageability (ISM): Yes
-
Intel® Control-Flow Enforcement Technology: Yes
-
Intel® AES New Instructions: Yes
-
Secure Key: Yes
-
Intel® OS Guard: Yes
-
Execute Disable Bit: Yes
-
Intel® Boot Guard: Yes
-
Mode-based Execute Control (MBEC): Yes
-
Intel® Virtualization Technology (VT-x): Yes
-
Intel® Virtualization Technology for Directed I/O (VT-d): Yes
-
Intel® VT-x with Extended Page Tables (EPT): Yes
-
