Specifications:
Console Dimensions and Weight
-
Size: Approximately 4.5 in (H) x 10.7 in (W) x 0.55 in (D) with Joy-Con 2 attached
-
Max Thickness (with sticks and ZL/ZR): 1.2 in
-
Weight (console only): Approximately 0.88 lbs
-
Weight (with Joy-Con 2 attached): Approximately 1.18 lbs
Display
-
Type: Capacitive touch screen
-
Size: 7.9-inch wide color gamut LCD
-
Resolution: 1920 x 1080
-
HDR: HDR10 support
-
Refresh Rate: VRR up to 120 Hz
Processor and Storage
-
CPU/GPU: Custom processor made by NVIDIA
-
Internal Storage: 256 GB UFS
-
Usable Storage: A portion reserved for system use
Connectivity
-
Wireless: Wi-Fi 6
-
Bluetooth: Supported
-
Wired LAN: Via dock in TV mode
Video Output
-
Output via: HDMI connector in TV mode
-
Max Resolution (TV mode): 3840 x 2160 (4K) at 60 fps
-
Max Frame Rate: 120 fps at 1080p or 1440p
-
HDR Support: HDR10
-
Max Resolution (handheld/tabletop): 1920 x 1080
Audio Output
-
HDMI Audio: Linear PCM 5.1ch supported
-
Speaker Output: Stereo
-
Speaker Enclosure: Independent design for clear sound
-
Headphones: Surround sound effect available with update
Microphone
-
Type: Built-in monaural
-
Features: Noise cancellation, echo cancellation, auto gain control
Ports and Slots
-
USB-C Ports: 2 (bottom for charging/dock, top for accessories)
-
Audio Jack: 3.5mm 4-contact stereo mini-plug (CTIA standard)
-
Game Card Slot: Compatible with Nintendo Switch and Nintendo Switch 2 game cards
-
microSD Slot: microSD Express cards only (up to 2TB)
-
Non-Express microSD: Limited to screenshot and video storage
Sensors
-
Console: Brightness sensor
-
Joy-Con 2 Controllers: Accelerometer, gyroscope, mouse sensor
Operating Environment
-
Temperature: 41–95°F
-
Humidity: 20–80%
Battery and Power
-
Internal Battery: Lithium-ion 5220mAh
-
Battery Life: Approximately 2 – 6.5 hours
-
Charging Time: Approximately 3 hours (in Sleep Mode)
Nintendo Switch 2 Dock
-
Size: Approximately 4.5 in (H) x 7.9 in (W) x 2 in (D)
-
Height with Feet: 4.58 in
-
Weight: Approximately 0.84 lbs
-
Ports: 2x USB (2.0), System Connector, AC Adapter Port, HDMI Port, LAN Port
-
Cooling: Built-in fan for heat management
Joy-Con™ 2 Controllers
Dimensions and Weight
-
Size: Approximately 4.57 in (H) x 0.56 in (W) x 1.2 in (D)
-
Joy-Con 2 [L] Weight: 2.3 oz
-
Joy-Con 2 [R] Weight: 2.4 oz
Buttons – Joy-Con 2 [L]
-
Left Stick (pressable)
-
Up/Down/Left/Right Buttons
-
L, ZL, SL, SR Buttons
-
Minus (-) Button
-
Capture Button
-
Release Button
-
Sync Button
Buttons – Joy-Con 2 [R]
-
Right Stick (pressable)
-
A/B/X/Y Buttons
-
R, ZR, SL, SR Buttons
-
Plus (+) Button
-
HOME Button
-
C Button
-
Release Button
-
Sync Button
Connectivity
-
Joy-Con 2 [L]: Bluetooth
-
Joy-Con 2 [R]: Bluetooth, NFC
Sensors
-
Both Controllers: Accelerometer, gyroscope, mouse sensor
Vibration
-
HD Rumble 2
Battery
-
Type: Lithium-ion
-
Capacity: 500mAh
-
Battery Life: Approximately 20 hours
-
Charging Time: Approximately 3 hours 30 minutes
-
Charging Method: Attached to console or Joy-Con 2 charging grip
Joy-Con 2 Strap
-
Size: Approximately 4.6 in (H) x 0.65 in (W) x 0.28 in (D) (excluding cord)
-
Weight: Approximately 0.25 oz (excluding cord)
Joy-Con 2 Grip
-
Size: Approximately 4.57 in (H) x 5.67 in (W) x 1.58 in (D)
-
Weight: Approximately 3.35 oz
