APC BX1600MI-MS BACK UPS 1600VA 230V WITH AVR

Specifications:

Main Features:

• Product Type: Uninterruptible Power Supply (UPS)
• Rated Power: 210W / 350VA
• Input Voltage: 230V AC
• Output Voltage: 230V AC
• Input Connection Type: IEC 60320 C14
• Output Connection Types:
  • 3 x IEC 60320 C13 outlets (battery backup and surge protection)
  • 1 x IEC 60320 C13 outlet (surge protection only)
  • 2 x IEC Jumpers
• Cable Length: 1.16 meters
• Number of Cables Included: 2
• Battery Type: Lead-acid battery
• Battery Voltage: 12V
• Battery Capacity: 7.0 Ah
• Battery Charger Power: 14W
• Battery Life: 4-6 years
• Battery Recharge Time: 6 hours
• Replacement Battery: RBC2
• Battery Power: 116 VAh capacity, 84 VAh runtime

Runtime and Performance:

• Run Time at Full Load (210W): 8 minutes 36 seconds (at 100% capacity used)
• Extended Runtime: None
• Transfer Time: 6 ms typical, 10 ms maximum
• Output Frequency: 50/60 Hz ± 1 Hz (unsynchronized to mains)
• Surge Energy Protection: 310 Joules
• Surge Protection Type: Full-time multi-pole noise filtering, 5% IEEE surge let-through, zero clamping response time (meets UL 1449)

Physical Dimensions and Weight:

• Height: 16.5 cm
• Width: 9.1 cm
• Depth: 28.4 cm
• Net Weight: 6.32 kg
• Mounting Location: Front
• Mounting Preference: No preference
• Rack-mountable: No

Environmental Conditions:

• Operating Temperature: 0C to 40C
• Storage Temperature: -15C to 45C
• Operating Humidity: 0% to 95% non-condensing
• Storage Humidity: 0% to 95% non-condensing
• Operating Altitude: 0 to 10,000 feet
• Storage Altitude: 0 to 15,240 meters
• Heat Dissipation: 19 Btu/h

Conformance and Certifications:

• Product Certifications: CE, C-Tick, GOST, VDE
• Standards:
  • EN/IEC 62040-1:2019/A11:2021
  • EN/IEC 62040-2:2006/AC:2006
  • EN/IEC 62040-2:2018
• Equipment Protection Policy: Lifetime coverage up to €šÂ¬100,000 / £50,000

Communication & Management:

• Control Panel: LED status display with indicators for online, on battery, replace battery, and overload
• Alarm:
  • On battery
  • Distinctive low battery alarm
  • Overload continuous tone alarm

Packaging:

• Unit Type of Package 1: PCE (Single Unit)
• Units in Package 1: 1
• Package Dimensions 1:
  • Height: 24.0 cm
  • Width: 19.0 cm
  • Length: 41.5 cm
  • Weight: 6.435 kg
• Unit Type of Package 2: PAM (Bulk Packaging)
• Units in Package 2: 70
• Package Dimensions 2:
  • Height: 142.0 cm
  • Width: 100.0 cm
  • Length: 120.0 cm
  • Weight: 492.45 kg

SCC14 Code: 10731304016349
