Specifications
-
Motherboard Support: Mini-ITX, Micro-ATX, ATX
-
Enclosure Type: Mid-Tower
-
Case Material: SGCC Steel, Ultra-clear Tempered Glass, Dark Tinted Tempered Glass
Dimensions
-
Height: 495mm (With Feet)
-
Width: 290mm
-
Depth: 466mm
-
Weight: 13.1 kg
Compatibility & Clearance
-
CPU Cooler Clearance: Up to 165mm
-
GPU Clearance: Up to 435mm
-
PSU Clearance: 200mm
-
Cable Management: 91mm
Front I/O Ports
- USB 3.2 Gen 1 Type-A: 2
- USB 3.2 Gen 2 Type-C: 1
- Headset Audio Jack: 1
Expansion Slots
Drive Bays
Fan Support
- Side: 3 x 120mm
- Top: 3 x 120mm / 2 x 140mm
- Bottom: 3 x 120mm / 2 x 140mm
- Rear: 1 x 120mm
- Filters: All Air Intakes
Radiator Support
- Side: Up to 360mm
- Top: Up to 360mm
- Bottom: Up to 360mm
- Rear: Up to 120mm
Fan Specs (F120Q - Case Version)
- Speed: 1200 ± 240RPM
- Airflow: 62.18 CFM
- Static: 1.05 mm - H2O
- Noise: 25.1 dBA
- Fan Connector: 3-pin
Fan Specs (F120RGB Duo)
- Speed: 500 ± 1800RPM
- Airflow: 48.58 CFM
- Static: 2.42mm - H2O
- Noise: 29 dBA
- Fan Connector: 4-pin
