TPLINK VIGI NVR1016H 16 CHANNEL NETWORK VIDEO RECORDER

Specifications:

• Video and Audio

  • IP Video Input: 16-Channel

  • Incoming Bandwidth: 80 Mbps

  • Outgoing Bandwidth: 60 Mbps

  • HDMI Output Resolution:

    • 3840 2160/30Hz

    • 1920 1080/60Hz

    • 1680 1050/60Hz

    • 1440 900/60Hz

    • 1280 1024/60Hz

    • 1280 720/60Hz

  • VGA Output Resolution:

    • 1920 1080/60Hz

    • 1680 1050/60Hz

    • 1440 900/60Hz

    • 1280 1024/60Hz

    • 1280 720/60Hz

  • Video Output Mode: HDMI/VGA Simultaneous Output

  • Multi-View Display: 1/4/6/8/9/16

• Decoding

  • Audio Compression: G.711A/G.711U/G.726

  • Decoding Format: H.265+/H.265/H.264+/H.264

  • Video Compression: H.265+/H.265/H.264+/H.264

  • Record Resolution:

    • 8MP, 5MP, 4MP, 3MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF

  • Live View/Playback Resolution:

    • 8 MP, 5 MP, 4 MP, 3 MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF

  • Synchronous Playback: 16-Channel

  • Capability:

    • 1-ch @ 8 MP

    • 2-ch @ 4 MP

    • 4-ch @ 2 MP

• Record Management

  • Record Mode:

    • Manual Recording

    • Scheduling Recording

    • Motion Detection Recording

  • Playback Mode:

    • Instant Playback

    • Regular Playback

    • Tag Playback

    • Event Playback

  • Backup Mode:

    • Regular Backup

    • Video Clip Backup

  • Playback Function:

    • Play, Pause, Stop, Fast Forward, Fast Backward, Play By Frame, Full Screen, Video Clip, Export Clip, Digital Zoom, Lock Recording, Audio On/Off

• Network

  • Protocol: TCP/IP, DHCP, DNS, NTP, UPnP

  • Mobile Phone Access: Android, iOS

  • Web Browser: Chrome (57+), Firefox (52+), Edge (91+)

  • Interoperability: ONVIF, CGI

• External Interface

  • Network Interface: 1, RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface

  • USB Interface: 2 USB 2.0

  • Audio Interface: 1, Audio In; 1, Audio Out

  • HDMI: 1

  • VGA: 1

• Hard Disk

  • SATA: 1 SATA Interface

  • Capacity: Up to 10 TB

• Alarm

  • General Alarm:

    • Motion Detection

    • Video Tampering

    • Line-Crossing Detection

    • Intrusion Detection

    • Region Entering/Exiting Detection

    • Object Abandoned/Removal Detection

    • Vehicle Detection

    • Human Detection

  • Anomaly Alarm:

    • Video Loss

    • Offline and IP Conflict

    • Disk Exception

    • Login Exception

  • Alarm Linkage:

    • Recording

    • White Light Alarm

    • Buzzer

    • Log

    • Audible Alarm

• General

  • Operating Temperature: -10‚¬"55 C

  • Storage Temperature: -40‚¬"70 C

  • Storage Humidity: 10%~90% RH Non-Condensing

  • Dimensions (W D H): 246.2 148.2 45 mm

  • Net Weight: 0.6 Kg

  • Gross Weight: 1.06 Kg

  • Power Consumption: 4.25 W (without disk), 13.10 W (with disk)

  • Certifications: CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, IC, HDMI

• Package Contents

  • VIGI Network Video Recorder

  • Power Adapter

  • HDD Screws

  • Mouse

  • Quick Installation Guide
