Specifications:
-
Application: Client PCs
-
Rated Capacity: 250GB (1GB = 1 billion bytes by IDEMA; actual usable capacity may be less due to formatting, partitioning, and system use)
-
Form Factor: M.2 (2280)
-
Interface: PCIe Gen 3.0 x4, NVMe 1.4
-
Dimensions (WxHxD): 80.15 x 22.15 x 2.38 mm
-
Weight: Max 8.0 g
-
Storage Memory: Samsung V-NAND 3-bit MLC
-
Controller: Samsung Pablo Controller
-
Cache Memory: HMB (Host Memory Buffer)
-
Special Features:
-
TRIM Support: Supported
-
S.M.A.R.T Support: Supported
-
Garbage Collection: Auto Garbage Collection Algorithm
-
Encryption Support: AES 256-bit Encryption (Class 0), TCG/Opal IEEE1667 (Encrypted drive)
-
WWN Support: Not supported
-
Device Sleep Mode Support: Yes
-
-
Performance:
-
Sequential Read Speed: Up to 2,900 MB/s (performance may vary based on system hardware & configuration)
-
Sequential Write Speed: Up to 1,300 MB/s (performance may vary based on system hardware & configuration)
-
Random Read (4KB, QD32): Up to 230,000 IOPS (performance may vary based on system hardware & configuration)
-
Random Write (4KB, QD32): Up to 320,000 IOPS (performance may vary based on system hardware & configuration)
-
Random Read (4KB, QD1): Up to 17,000 IOPS (performance may vary based on system hardware & configuration)
-
Random Write (4KB, QD1): Up to 53,000 IOPS (performance may vary based on system hardware & configuration)
-
-
Environment:
-
Average Power Consumption: Average: 3.7 W, Maximum: 5.6 W (Burst mode) (actual power consumption may vary depending on system hardware & configuration)
-
Power Consumption (Idle): Max. 45 mW (actual power consumption may vary depending on system hardware & configuration)
-
Allowable Voltage: 3.3 V ± 5%
-
Reliability (MTBF): 1.5 million hours
-
Operating Temperature: 0 - 70°C
-
Shock Resistance: 1,500 G & 0.5 ms (Half sine)
-
-
Accessories: Installation Kit not available
-
Software: Magician Software for SSD management
-
Warranty: Five (5) year limited warranty or 150 TBW limited warranty
