Specifications:
-
Rated Capacity:
-
500 GB (1 GB = 1 Billion bytes by IDEMA; actual usable capacity may be less due to formatting, partitioning, and other factors)
-
-
Form Factor:
-
2.5 inch
-
-
Interface:
-
SATA 6 Gb/s (compatible with SATA 3 Gb/s & SATA 1.5 Gb/s)
-
-
Dimensions (Pack: WxHxD):
-
100 x 69.85 x 6.8 mm
-
-
Weight:
-
Approx. 45.0 g
-
-
Storage Memory:
-
Samsung V-NAND 3bit MLC
-
-
Controller:
-
Samsung MKX Controller
-
-
Cache Memory:
-
Samsung 512 MB Low Power DDR4 SDRAM
-
-
Special Features:
-
TRIM Support
-
S.M.A.R.T Support
-
Auto Garbage Collection Algorithm
-
AES 256-bit Encryption (Class 0), TCG/Opal, IEEE1667 (Encrypted drive)
-
World Wide Name (WWN) support
-
Device Sleep Mode Support
-
-
Performance:
-
Sequential Read: Up to 560 MB/s (Performance may vary based on system hardware & configuration)
-
Sequential Write: Up to 530 MB/s (Measured with Intelligent TurboWrite technology activated; Performance may vary)
-
Random Read (4KB, QD32): Up to 98,000 IOPS (Measured with Intelligent TurboWrite technology activated; Performance may vary)
-
Random Write (4KB, QD32): Up to 88,000 IOPS (Measured with Intelligent TurboWrite technology activated; Performance may vary)
-
Random Read (4KB, QD1): Up to 13,000 IOPS (Measured with Intelligent TurboWrite technology activated; Performance may vary)
-
Random Write (4KB, QD1): Up to 36,000 IOPS (Measured with Intelligent TurboWrite technology activated; Performance may vary)
-
-
Environment:
-
Average Power Consumption: 2.2 W (maximum 3.5 W in burst mode; actual power consumption may vary)
-
Power Consumption (Idle): Max. 30 mW (actual power consumption may vary)
-
Allowable Voltage: 5V ± 5%
-
Operating Temperature: 0 - 70 ℃
-
Shock Resistance: 1,500 G & 0.5 ms (Half sine)
-
-
Accessories:
-
Installation Kit: Not Available
-
-
Software:
-
Magician Software for SSD management
-
Data Migration Software for SSD upgrade
-
-
Warranty:
-
5 Years Limited Warranty or 300 TBW Limited Warranty
-
