TPLINK VIGI NVR1016H 16 CHANNEL NETWORK VIDEO RECORDER

0 Review
₱4,490.00
Availability: In stock
SKU:
SUR-TL-NVR-VIGINVR1016H

The VIGI NVR1016H is a robust 16-channel network video recorder designed for continuous 24/7 recording, accommodating up to 10 TB of footage for convenient access. It supports real-time live viewing in sharp 8MP resolution and features quick lookup for easy playback by date or event type. With H.265+ compression technology and ONVIF compatibility, it ensures efficient storage and seamless integration with cameras from various brands.

Brands:

Specifications:



  • Video and Audio

    • IP Video Input: 16-Channel

    • Incoming Bandwidth: 80 Mbps

    • Outgoing Bandwidth: 60 Mbps

    • HDMI Output Resolution:

      • 3840 × 2160/30Hz

      • 1920 × 1080/60Hz

      • 1680 × 1050/60Hz

      • 1440 × 900/60Hz

      • 1280 × 1024/60Hz

      • 1280 × 720/60Hz

    • VGA Output Resolution:

      • 1920 × 1080/60Hz

      • 1680 × 1050/60Hz

      • 1440 × 900/60Hz

      • 1280 × 1024/60Hz

      • 1280 × 720/60Hz

    • Video Output Mode: HDMI/VGA Simultaneous Output

    • Multi-View Display: 1/4/6/8/9/16

  • Decoding

    • Audio Compression: G.711A/G.711U/G.726

    • Decoding Format: H.265+/H.265/H.264+/H.264

    • Video Compression: H.265+/H.265/H.264+/H.264

    • Record Resolution:

      • 8MP, 5MP, 4MP, 3MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF

    • Live View/Playback Resolution:

      • 8 MP, 5 MP, 4 MP, 3 MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF

    • Synchronous Playback: 16-Channel

    • Capability:

      • 1-ch @ 8 MP

      • 2-ch @ 4 MP

      • 4-ch @ 2 MP

  • Record Management

    • Record Mode:

      • Manual Recording

      • Scheduling Recording

      • Motion Detection Recording

    • Playback Mode:

      • Instant Playback

      • Regular Playback

      • Tag Playback

      • Event Playback

    • Backup Mode:

      • Regular Backup

      • Video Clip Backup

    • Playback Function:

      • Play, Pause, Stop, Fast Forward, Fast Backward, Play By Frame, Full Screen, Video Clip, Export Clip, Digital Zoom, Lock Recording, Audio On/Off

  • Network

    • Protocol: TCP/IP, DHCP, DNS, NTP, UPnP

    • Mobile Phone Access: Android, iOS

    • Web Browser: Chrome (57+), Firefox (52+), Edge (91+)

    • Interoperability: ONVIF, CGI

  • External Interface

    • Network Interface: 1, RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface

    • USB Interface: 2× USB 2.0

    • Audio Interface: 1, Audio In; 1, Audio Out

    • HDMI: 1

    • VGA: 1

  • Hard Disk

    • SATA: 1 SATA Interface

    • Capacity: Up to 10 TB

  • Alarm

    • General Alarm:

      • Motion Detection

      • Video Tampering

      • Line-Crossing Detection

      • Intrusion Detection

      • Region Entering/Exiting Detection

      • Object Abandoned/Removal Detection

      • Vehicle Detection

      • Human Detection

    • Anomaly Alarm:

      • Video Loss

      • Offline and IP Conflict

      • Disk Exception

      • Login Exception

    • Alarm Linkage:

      • Recording

      • White Light Alarm

      • Buzzer

      • Log

      • Audible Alarm

  • General

    • Operating Temperature: -10–55 °C

    • Storage Temperature: -40–70 °C

    • Storage Humidity: 10%~90% RH Non-Condensing

    • Dimensions (W × D × H): 246.2 × 148.2 × 45 mm

    • Net Weight: 0.6 Kg

    • Gross Weight: 1.06 Kg

    • Power Consumption: 4.25 W (without disk), 13.10 W (with disk)

    • Certifications: CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, IC, HDMI

  • Package Contents

    • VIGI Network Video Recorder

    • Power Adapter

    • HDD Screws

    • Mouse

    • Quick Installation Guide
